Overview

"8K shot, more possibilities Sony Sensor SOOC 48MP photos In-camera 4K 10-bit HDR enables the presentation of authentic brightness Time-lapse photography 6K SOOC Instant focusing"

More Info

• Compatible with DJI PSDK enabled drones(with mounting kit).
• Standalone operation, with optional external trigger and data from host aircraft.
• Five narrow spectral bands captured during flight.
• High image resolution; 5.2 cm/pixel at 400 ft (120 m).
• USB 3.0 Compatible Storage Devices
• High Resolution Global shutter imagers aligned with all bands – no gimbal required.

What's Included

Camera kit includes DLS 2.0 and Calibration Panel

Specifications

ISO Range: Video 100-6400 ;Photo 100-3200

Lens: FOV 79.1° ± 3°

Electronic Shutter: 1/8000 - 8s

Highest Resolution for Images: 48MP: 8000 (H) x 6000 (V)

Highest Resolution for Videos: 8K7680 (H) x 4320 (V) (recording) (16:9)

• Weight: 357 g (12.6 oz). With DLS2 = 406.5 g (14.34 oz)
• Dimensions: 8.2 cm x 6.7 cm x 6.45 cm (3.2 in x 2.5 in x 2.5 in)
• External Power: 4.9 V DC – 25.2 V DC (5.5/7/10W Standby, average, peak)
• Spectral Bands:
• >>EO: Blue, green, red, red edge, near infrared (NIR)
• >>LWIR: thermal infrared (8-14 um)
• Wavelength (nm) Blue (475 nm center, 20 nm bandwidth), green (560 nm center, 20 nm bandwidth), red (668 nm center, 10 nm bandwidth), red edge (717 nm center, 10 nm bandwidth), near-IR (840 nm center, 40 nm bandwidth)
• Sensor Resolution: 2064 x 1544 (3.2 MP per EO band), 160 x 120 thermal infrared
• Ground Sample Distance (GSD): 5.2 cm per pixel (per EO band) at 120m. 81cm per pixel (thermal) at 120 m (~400 ft) AGL
• Capture Rate: 1 capture per second (all bands), 12-bit RAW
• Interfaces: Aircraft: trigger input, top of frame out, 1 PPS out. 3.3V isolated IO. 2x USB 3.0 SuperSpeed ports for WiFi or Ethernet and USB 3.0 Storage
• Focal Length 8mm (multispectral), 1.77 mm (thermal)
• Field of View: 48° x 37° (multispectral) 57° x 44° (thermal)
